Production Facilities

Extrusion [JC]

Extruder → Extruder Setup (JC-00) → Raw Material Loading (JC-01) → Traction Setup (JC-02)

-

-

1. Process Parameter Sheet 2. Equipment Checklist 3. Extrusion Inspection Record 4. 5S Checklist

Cutting [QG]

Cutting Machine → Cutting Machine Setup (QG-00) → Visual Inspection (QG-01) → Dimension Inspection (QG-02)

01. Plain-End Tube

1. Water Inflow (Volume Test) 2. Tube Outer Diameter 3. Tube Weight 4. Tube Appearance & Deflection 5. Cut Surface

1. Process Parameter Sheet 2. Equipment Checklist 3. Extrusion Inspection Record 4. 5S Checklist

Ultrasonic [CS]

Ultrasonic Machine → Ultrasonic Machine Setup (CS-00) → Tube Loading (CS-01) → Tube Tail Welding (CS-02) → Tube Head Welding (CS-03) → Visual Inspection (CS-04) → Strength Test (CS-05)

02. Ultrasonic Welded Tube

1. Ultrasonic Strength, Deflection, Glue Seepage & Cracking 2. Tube Appearance

1. Process Parameter Sheet 2. Equipment Checklist 3. Ultrasonic Patrol Inspection Record 4. 5S Checklist

Leak Testing [CL]

Leak Tester → Parameter Setting (CL-00) → Air Tightness Test (CL-01) → NG Product Removal (CL-02)

-

-

1. Process Parameter Sheet 2. Equipment Checklist 3. 5S Checklist

Plug Insertion [SX]

Plug Insertion Machine → Parameter Setting (SX-00) → Tube Tail Plug Insertion (SX-01) → Plug Insertion Inspection (SX-02) → NG Product Removal (SX-03)

03. Non-Graduated Finished Tube

-

1. Process Parameter Sheet 2. Equipment Checklist 3. 5S Checklist

Printing [YS]

Printing Machine → Printing Machine Setup (YS-00) → Printing Material Loading (YS-01) → Visual Inspection (YS-02) → Function Test (YS-03) → NG Product Handling (YS-04)

04. Printed Tube

1. Printing Effect 2. Ink Adhesion 3. Graduation Line Accuracy

1. Process Parameter Sheet 2. Equipment Checklist 3. Printing Inspection Record 4. 5S Checklist

Packaging [BZ]

Packaging Machine → Setup Preparation (BZ-00) → Packaging Material Loading (BZ-01) → Loading Inspection (BZ-02) → Performance Test (BZ-03) → Finished Product Inspection (BZ-04) → NG Product Handling (BZ-05)

05. Individually Packaged Tube

1. Heat Sealing Effect 2. Heat Seal Tensile Force 3. Loading Confirmation

1. Packaging Process Parameter Sheet 2. Equipment Checklist 3. Packaging Patrol Inspection Record 4. Packaging Self-Inspection Record 5. 5S Checklist

Boxing [ZX]

Boxing Machine → Printing Confirmation (ZX-01) → Weighing & Sealing (ZX-02) → Boxing & Labeling (ZX-03) → Palletizing (ZX-04) → Factory Inspection (ZX-05) → NG Product Handling (ZX-06)

06. Finished Product

-

1. Factory Inspection Report 2. Product Sample
